E190CG

Introduction

Specification

Documents

Related Product

E190CG

Jusha display for endoscopic surgery only uses LCD panel with accurate color reproduction,good sense of hierarchy,smooth dynamic display and wide visual range.It satisfy the rapid changing needs for medical display.In minimally invasive surgery (MIS),it can clearly observe the position of surgery.The white frame,the compliance with electromagnetic compatibility and many video input and output interfaces make the product fully meet the requirements of various endoscopy or operating room and ICU display.
Introduction

1.Characteristics

With the 36 bit technology, JUSHA display for endoscopic surgery only can represent over 68.7 billion colors and accurately reproduce the colors of human issues in MIS, so that the surgeons can make more accurate judgments.


2.Good sense of hierarchy

The most advanced medical LCD panel used by JUSHA display for endoscopic surgery only has good sense of hierarchy, high brightness and high contrast, thus it can represent the hierarchy of any issue in the surgery and provide clear clinical surgery images.


3.Smooth dynamic image

The response time of the gray scale of JUSHA display for endoscopic surgery only is less than 14ms, thus it can smoothly present the surgery images from standard definition to high definition and clearly display bleeding and other meticulous operations in the surgery without smearing and shaking.


4.Compliance with the requirements of cleansing and anti-interference in the operating room

The white dust-free design used by JUSHA display for endoscopic surgery only meets the cleansing requirements of operating equipment in the operating room. The closed metal design can effectively prevent dust and liquid pollution during the surgery. The body with metal shell and the built-in shield circuit can effectively prevent the interference of electric operating equipment such as high frequency electric knife to the monitor, thus it can ensure the stability of surgical display.


5.Various types of interfaces

JUSHA display for endoscopic surgery only can be compatible with various analog signals and digital signals as well as the image pick-up systems of hard lens manufactures and soft lens manufactures in the world. lt fully meets the needs of various brands and equipment.


Specification
Model No: E190CG
Modello E190CG
Tipo IPS
Задняя фара LED
Область отображения 19''(479.96mm)
Область отображения 374.784 × 299.827 mm
С резолюцией 1540 (2004) 1280 × 1024
Соотношение сторон 5:4
Пиксель-поле 0.2928 × 0.2928 mm
Глубина цвета 8 bit
Глубина LUT 12 bit
Углы обзора 178°
Максимальная калиброванная яркость 250 cd/m²
Максимальная калиброванная яркость 200 cd/m²
Яркость по умолчанию 150 cd/m²
Минимальная яркость света 100 cd/m²
Количество пресетов GAMMA1.8, GAMMA2.0, GAMMA2.2, GAMMA2.4, GAMMA2.6,DICOM
Коэффициент контрастности 1000:1
Время отклика (т + тофф)/2 14 ms
Особенности сайта PIP
Ввод видео данных DVI × 1, VGA × 1, CVBS × 1, S-VIDEO × 1, YPbPr × 1, RGBS × 1
Видео выход на экран DVI × 1, CVBS × 1, S-VIDEO × 1, YPbPr × 1, RGBS × 1
Прочие I/O USB-A (DC 5V 0.5A Output) × 1
Потребляемая мощность DC: 12V, 5A Power AC: 100~240V, 50/60Hz
Типичная мощность 25W
Максимальная мощность 60 W
Экономия электроэнергии < 0.5 W
Цвет корпуса Цвет: белый
Размеры стенда (ш x в x г) 421.8 × 404.2 × 204 mm
Размеры без опоры (ш x в x г) 421.8 × 344 × 63.7 mm
Вес нетто со стендом 6.9Kg
Вес нетто без опоры 5.5Kg
VESA 100 × 100 mm
Certificazioni CCC
