Homepage  >  Продукц  >  Монитор для хирургических операций  >  Эндоскопия (эндоскопия)
E240CG

Introduction

Specification

Documents

Related Product

E240CG

JUSHA endoscopic operating room professional displays adopt widescreen full HD LCD panels with accurate color rendering, excellent layering smooth and dynamic images and an expanded visual scope, which meet the current rapidly changing demands for medical displays and is able to provide clear and precise observation of surgical sites in minimally invasive surgery (MIS).This product is perfectly suited to meet the requirements of various kinds of endoscopic displays or operating room and ICU displays due to its white frame, water-proof design, antibacterial-Al treatment, compliance with electromagnetic compatibility regulations and multiple video input/output interfaces.
Introduction

1. Accurate color reproduction

All professional monitors in JUSHA surgical monitor product line applies 36bit LUT technology, which can linearly represent more than 68.7 billion colors, to accurately restore the color of human body, so that surgeons can make more accurate judgments.



2. High color depth

This JUSHA surgical monitor adopts the highest-level medical liquid crystal panel, which has good color, high brightness and high contrast, so that the layers of each tissue in the operation are well expressed and the clinical image is clear and vivid.



3.Smooth dynamic motion

The response time of this JUSHA surgical monitor is less than 14ms, so that I can smoothly present surgical videos from standard resolution to ultra-high resolution, and clearly display the bleeding status and other delicate operations during the operation, without smear and jitters.



4. Meet the operating room purification and anti-interference requirements

This JUSHA surgical monitor adopts a dust-free design, which meets the purification requirements of the operating room for surgical equipment. The fully enclosed design can effectively prevent dust and liquid pollution during the operation. The body of the metal shell and the built-in shielding circuit can effectively prevent the interference of electronic surgical equipment such as high frequency electrosurgery on the monitor and ensure the stability of the display.



5. Various interfaces

This JUSHA surgical monitor can be compatible with a variety of analog signals and digital signals and can be fully compatible with the world's major camera systems.


Specification
Model No: E240CG
Modello E240CG
Tipo IPS
Задняя фара LED
Область отображения 24'' (611.3 mm)
Область отображения 518.4 × 324 mm
С резолюцией 1540 (2004) 1920 × 1200
Соотношение сторон 16:10
Пиксель-поле 0.27 × 0.27 mm
Глубина цвета 8 bit
Глубина LUT 12 bit
Углы обзора 178°
Максимальная калиброванная яркость 600 cd/m²
Максимальная калиброванная яркость 450 cd/m²
Яркость по умолчанию 300 cd/m²
Минимальная яркость света 150 cd/m²
Количество пресетов GAMMA1.8, GAMMA2.0, GAMMA2.2, GAMMA2.4, GAMMA2.6,DICOM
Коэффициент контрастности 1000:1
Время отклика (т + тофф)/2 14 ms
Особенности сайта PIP
Ввод видео данных DVI × 1, VGA × 1, CVBS × 1, S-VIDEO × 1, YPbPr × 1, RGBS × 1, SDI × 1
Видео выход на экран DVI × 1, CVBS × 1, S-VIDEO × 1, YPbPr × 1, RGBS × 1, SDI ×1
Прочие I/O USB-A (DC 5V 0.5A Output) × 1
Потребляемая мощность "DC: 24V, 3.75A Power AC: 100~240V, 50/60Hz"
Типичная мощность 30 W
Максимальная мощность 90 W
Экономия электроэнергии < 0.5 W
Стабилизатор заднего освещения Yes
Цвет корпуса Цвет: белый
Размеры стенда (ш x в x г) 565.3 × 469 × 211 mm
Размеры без опоры (ш x в x г) 565.3 × 375.3 × 63.3 mm
Вес нетто со стендом 10.85 Kg
Вес нетто без опоры 6.55 Kg
VESA 100 × 100 mm
Certificazioni CCC, CE
Documents
